Lead Continuous Extruder Machine for wire and cable making

FOB Reference Price:Get Latest Price
$10,000.00 - $40,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
Shineworld
Model Number:
SW-200/5
Usage:
Extruding
Application:
make lead sheath for wire anc cable
Method:
continous extruding
extruding raw material:
Lead
Voltage:
380V/415V/440V/480V
Frequency:
50HZ/60HZ
PLC:
Siemens brand
Low Voltage component:
Schneid brand
Color:
green or costomized
Supply Ability
Supply Ability:
30 Set/Sets per Year
Packaging & Delivery
Packaging Details
Wood and China standard package
Port
China port

1. Brief Introduce



 This Lead Continuous Extruder Machine  for wire and cable making is used to

1.1 apply lead sheathing to cables

1.2 or vulcanize rubber tube for the production of cables.



2. principle



Outer diameter of lead layer can be made betweenΦ70 and Φ160mm,

With a screw to feed lead from the downward to the upward in the way of vertical rotation ,

 it is possible to achieve continuous extrusion,

 so thickness of lead layer keeps constant and even in longitudinal direction.



At the same time because the temperature at each part can be strictly controlled,

and make the extruding pressure and temperature keep constant,

 the error value of the lead layer thickness is guaranteed to be minimized.



3. Design advantage



It adopt sealing system design for the melting furnace, the purifying & holding furnace,

 and lead conveyor, So the distribution of steam is greatly minimized.



 4. Machine advantage

4.1 Save space due to compact design

4.2 Machine is light weight

4.3 Low in labor intensity







5. Main specification





Pure lead or alloyed lead to continuously extrude.





 Component of lead     screw rotating speed(r/min)  extrusion output(kg/min)



Pure lead                     7~12                    30~42



Soft alloyed lead               6~9                    15~26



Hard alloyed lead              6~9                    13~24





Technical Parameter

Model

SW-45

SW-65

SW-80

Dia. Screw(mm)

45

65

90

Length-Dia. ratio

25:1

25:1

25:1

Main motor power (KW)

11

22

30

Conductor (mm²)

0.35-1.5

0.35-2.5

1.0-6.0

insulation thickness(mm)

0.1-2.0

Wire OD(mm)

1.0-2.5

1.0-4.0

1.5-7.0

Line speed (m/min)

MAX500

MAX500

MAX500

Material

PVC/XLPE/HFFR

Max. extrusion capacity (PVC) (KG/h)

50

130k

200

Max. extrusion capacity (XLPE) (KG/h)

35

90 k

220

Pay off spool

400-630

400-630



Cooling system

Single layer/double layer water trough

Capstan

Dual wheel

Dual wheel

Dual wheel

Capstan wheel size

318

500

500

Accumulator capacity

200m

Capstan motor(KW)

2.2

4

5.5

Take up spool

300-400

500-630

500-630

Take up motor(KW)

2.2

4

4


Product show





Procedure







Success Case



Related Products





Company Power







Exhibition



FAQ

1,Q: What is your main brand for the electrical and mechanical parts?
A: China famous brand



2, Q:could we appoint the parts brand?
A: Yes, ABB, SIEMENS, Danfoss, or theirs that you like.



3, Q: could you please arrange the installation and commissioning ?
A: Yes , we could and the buyer pay the charge



4, Q: could you arrange the production education?
A: Yes , we could and the buyer pay the charge



5, Q: could you do the design for the whole plant
A: Yes , we can.



6, Q: could you offer the production process design
A: Yes , we can.



7, Q: what is the difference with other supplier?
A: what we could offer to other customer is not only the machine itself, also we could offer: factory design, production process design , QC control and education and assist machine and raw material offering .



8.Q:What's the payment terms?
A:T/T,30% deposit and 70% balance before delivery.



9, Q:How long the guarantee:
A: one year and charge for repair the whole life.
